Stickney Rotary Press


Previous Page

To participate in the forum you must log in or register.
Author Previous Topic Topic Next Topic
Page: of 4
Pillar Of The Community
2768 Posts
Posted 05/15/2018   12:08 pm  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
Galeoptix: The teeth are not equal to pins in this case but pins are equal to holes. The length used encompasses all of the holes between the (tooth) left of the left most hole and the (tooth) right of the right most hole. If I was measuring from middle hole to middle hole, I know that the first and last holes would each count as a half hole. However, I am trying to determine a perforating bar (equipment) measurement here rather than only just a stamp perforation gauge reading. From my own perforation gauging of this line, I have found it to be around 12.6 whereas the catalogues have it as 12.5 (12 1/2).
Send note to Staff  Go to Top of Page
Edited by jogil - 05/15/2018 12:15 pm
Pillar Of The Community
Netherlands
648 Posts
Posted 05/15/2018   12:36 pm  Show Profile Bookmark this reply Add Galeoptix to your friends list  Get a Link to this Reply
Jogil,

so if "The length used encompasses all of the holes between the (tooth) left of the left most hole and the (tooth) right of the right most hole." then you have counted 2 half-holes too many!??!?!

!ototototo!
Send note to Staff  Go to Top of Page
Pillar Of The Community
2768 Posts
Posted 05/15/2018   1:12 pm  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
Galeoptix:

165 (half) teeth means 164 holes which is where I got the 10.25" at

since I did not get the 10.25" from 164 (half) holes

165 (half) holes means 164 teeth
Send note to Staff  Go to Top of Page
Edited by jogil - 05/15/2018 2:10 pm
Pillar Of The Community
2768 Posts
Posted 05/16/2018   07:29 am  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
Here is an interesting full sheet from Czechoslovakia. It is a sheet rather than a pane because it is the same as the plate layout of 20 x 10 = 200 stamps which was not broken down but issued this way. It is also Stickney rotary press printed. On the press, there were two such printing plates of 200 (20 x 10) stamp subjects. See pictures:




Note the vertical printing plate line on the leftmost part of the sheet and the vertical wavy cutting line on the leftmost and rightmost part of the sheet, the vertical gum breakers across all the sheet, the short vertical running perforations in the selvage margins, the short gum coverage in the selvage margins which are all typical of Stickney rotary press printed stamps. Also, since it is ten stamps across in the same direction of both the gum breakers and the short running perforations, a small Stickney press was used.
Send note to Staff  Go to Top of Page
Edited by jogil - 05/16/2018 08:03 am
Pillar Of The Community
2768 Posts
Posted 05/17/2018   09:36 am  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
I am trying to measure the perforating bar perforations on early Stickney press printed Czechoslovakia stamps (1925-1935). This would represent the limiting size side or shortest side since the perforations do not go all the way across the selvage margins but stop there.

I got 128 holes in a 10.25" length which is 128/10.25/1.27 = 9.83 perforations per 2 cm and 1/(128/10.25) = 0.080" between holes. This appears to be the same gauge as for U.S. Stickney press coils. The stamp catalogues have this as perforation 10 or 9 3/4 gauge.

Send note to Staff  Go to Top of Page
Edited by jogil - 05/17/2018 09:43 am
Pillar Of The Community
Czech Republic
547 Posts
Posted 05/21/2018   04:42 am  Show Profile Bookmark this reply Add florian to your friends list  Get a Link to this Reply
jogil - Thanks for pointing out on http://goscf.com/t/36707&whichpage=4#536511 that the sheet of stamps was printed on a small Stickney press.

As there were only two such printing plates of 200 (20 x 10) small stamp subjects on either of our Stickney presses, I have to correct my post on http://goscf.com/t/36707&whichpage=3#536204 , where I wrongly inferred that both Stickney presses used in Czechoslovakia were large machines.
Send note to Staff  Go to Top of Page
Edited by florian - 05/21/2018 04:44 am
Pillar Of The Community
2768 Posts
Posted 05/23/2018   10:35 am  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
Czechoslovakia appears to be the country that has printed the most Stickney rotary press stamps from 1925 to 1959 after the United States.

The following is a listing of all of the Stickney rotary press printed Czechoslovakia stamps by Scott/Pofis catalogue numbers:

Sheet stamps line-perforated gauge 9 3/4 horizontally by 9 3/4 vertically:
105/199, 105/200, 106/201, 109/212, 110/214, 111/215, 114/210, 115/211, 116/204, 117/205, 118/213, 126/217, 127/218, 128/206, 129/207, 130/203, 131/208, 132/219, 133/220, 134/221, 135/222, 136/224, 152/248, 153/249, 154/250, 155/251, 156/252, 157/253, 164/223, 168/258, 169/259, 170/260, 184/265, 185/266, 186/267, 187/268, 188/269, 189/270, 190/271, 191/272, 192/273, 193/274, 194/275, 195/276, 196/277, 197/278, 198/279, 199/280, 200/281, 201/282, 202/285, 203/286, 204/287, 205/288, 206/289, 207/290, 208/291, 209/292, 210/293, 211/294.

Coil stamps line-perforated gauge 9 3/4 vertically: 123/209A, 124/210A, 125/---?, 141/216, 158/250A, 171/260A.

Sheet stamps line-perforated gauge 12 1/2 horizontally by 12 1/2 vertically:
212/303, 213/298, 214/299, 215/300, 216/301, 217/302, 218/304, 219/305, 220/307, 221/308, 222/309, 223/310, 224/311, 225/312, 226/313, 227/314, 228/318, 229/319, 230/320, 231/321, 232/322, 233/323, 234/324, 235/325, 236/326, 237/327, 238/328, 240/306, 241/331, 242/332, 243/336, 244/337, 245/338, 246/339, 247/340, 248/341, 249/344, 250/345, 252/346, 253/348, 254/349, 254A/350, 254B/351, 255/O351, 256/352, 259/376, 259A/377, 260/378, 261/379, 262/380, 293/413, 294/415, 295/418, 295A/419, 296/421, 297/422, 297A/423, 298/424, 299/425, 300/426, 300A/428, 305/431, 306/432, 315/436, 316/438, 317/439, 318/443, 319/444, 320/445, 321/446, 322/447, 323/448, 324/449, 325/417, 326/450, 327/451, 328/452, 329/453, 330/454, 331/455, 332/456, 333/457, 334/458, 335/459, 336/460, 337/461, 343/467, 344/468, 345/469, 346/470, 347/471, 348/472, 349/473, 351/475, 352/476, 353/477, 354/478, 355/479, 356/480, 357/481, 358/482, 359/483, 360/484, 361/490, 362/491, 363/485, 364/486, 364a/487, 365/488, 366/489, 369/493, 370/498, 371/499, 373/501, 378/506, 379/507, 380/508, 381/509, 382/510, 383/511, 384/512, 385/513, 386/514, 387/515, 388/516, 389/517, 390/518, 391/519, 392/520, 393/521, 394/522, 395/523, 396/524, 397/525, 398/526, 399/531, 400/532, 401/533, 403/535, 404/536, 405/537, 406/538, 407/539, 408/540, 409/541, 410/542, 411/543, 412/544, 413/545, 414/546, 415/547, 416/548, 417/549, 418/550, 419/551, 420/552, 421/553, 422/556, 423/557, 424/554, 425/555, 430/565, 431/566, 432/567, 433/568, 434/562, 435/563, 436/569, 437/570, 440/573, 442/575, 443/576, 444/577, 448/581, 449/582, 452/585, 453/586, 454/587, 455/588, 456/589, 457/590, 458/591, 459/592, 460/593, 463/596, 464/597, 465/598, 466/599, 467/600, 468/601, 469/602, 470/603, 471/604, 472/605, 473/608, 474/611, 477/606, 478/607, 479/612, 480/613, 481/614, 483/616, 484/617, 485/618, 487/620, 489/622, 491/623, 492/624, 497/629, 498/630, 507/640, 508/641, 509/642, 510/643, 511/636, 512/646, 513/647, 523/655, 524/656, 525/657, 526/658, 527/659, 528/660, 532/664, 533/665, 534/667, 535/668, 536/669, 537/670, 538/671, 539/672, 544/677, 545/678, 548/683, 551/686, 557/693, 558/694, 559/695, 564/666, 600/732, 602/734, 607/743, 608/744, 618/741, 645/775, 646/776, 647/777, 648/778, 649/779, 650/780, 651/781, 652/782, 653/783, 780/---?, 870/999, 870A/1091, 871/1000.

B144/295, B145/296, B146/297, B147/315, B148/316, B149/317, B150/333, B151/334, B154/429, B155/430, B156/433, B157/434, B163/494, B164/495, B165/496, B166/529, B167/530, B168/527, B169/528.

C19/L17, C20/L18, C21/L19, C22/L20, C23/L21, C24/L22, C25/L23, C26/L16, C27/L24, C28/L25, C29/L26, C30/L27, C31/L28, C32/L29, C33/L30, C34/L31, C35/L32.

J82/DL79, J83/DL80, J84/DL81, J85/DL82, J86/DL83, J87/DL84, J88/DL85, J89/DL86, J90/DL87, J91/DL88, J92/DL89, J93/DL90, J94/DL91.

Bohemia and Moravia sheet stamps line-perforated gauge 12 1/2 horizontally by 12 1/2 vertically:

1/1, 2/2, 3/3, 4/4, 5/5, 6/6, 7/7, 8/8, 9/9, 10/10, 11/11, 12/12, 13/13, 14/14, 15/15, 16/16, 17/17, 18/18, 19/19, 27/28, 28/29, 29/30, 30/31, 31/32, 32/33, 33/34, 34/35, 35/36, 36/37, 37/38, 38/39, 39/40, 40/41, 41/42, 42/43, 43/44, 44/45, 45/46, 46/47, 47/48, 48/49, 49/54, 50/55, 51/56, 52/57, 53/58, 53A/59, 53B/60, 53C/61, 54/62, 55/63, 60/72, 61/73, 68/84, 69/85, 70/86, 71/87, 72/88, 73/89, 74/90, 75/91, 76/92, 77/93, 78/94, 79/95, 80/96, 81/97, 82/98, 83/99, 88/120, 89/121, 90/122.

B9/74, B10/75, B11/76, B12/77, B18/106, B19/107, B27/118, B28/119.

Slovakia sheet stamps line-perforated gauge 12 1/2 horizontally by 12 1/2 vertically:

2/2, 3/3, 4/4, 5/5, 6/6, 7/7, 8/8, 9/9, 10/10, 11/11, 12/12, 13/13, 14/14, 15/15, 16/16, 17/17, 18/18, 19/19, 20/20, 21/21, 22/22, 23/23.
Send note to Staff  Go to Top of Page
Pillar Of The Community
2768 Posts
Posted 05/23/2018   10:44 am  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
After the United States and Czechoslovakia, North Korea appears to have printed the third most number of stamps with a Stickney rotary press from 1962 to 1966 which Czechoslovakia provided it with in 1961 and which was used to print the following stamps perforated gauge 12 1/2 horizontally by 12 1/2 vertically by Scott/Michel catalogue numbers:

298/447A, 299/447B, 300/448, 304/449, 305/450, 309/388, 310/451, 311/452, 312/573, 313/453, 314/454, 315/455, 395/391, 396/392, 397/393, 398/394, 399/395, 400/396, 401/397, 402/398, 403/399, 404/400, 425/421, 448/444, 449/445, 450/446, 459/464, 477/482, 478/484, 479/483, 480/485, 481/486, 482/487, 483/488, 484/489, 491/496, 492/499, 493/497, 494/498, 503/508, 504/509, 505/510, 507/512, 512/517, 513/518, 514/519, 517/---?, 521/525, 522/526, 523/552, 537/540A, 538/541A, 544/547, 545/548A, 546/549A, 547/550A, 548/551, 554/558, 555/559, 556/561, 557/560, 565/569, 569/574, 570/575, 571/576, 577/582, 578/583, 586/591, 589/594, 590/602, 591/601, 592/603, 602/607, 614/619, 615/620, 622/627, 623/628, 624/632, 625/630, 626/631, 627/629, 632/637, 633/638, 639/639, 640/640, 641/641, 642/647, 643/648, 644/649, 645/650, 677/684, 678/682, 679/683, 680/685, 681/686, 682/687, 688/693, 689/694, 709/715, 710/716, 711/714, 719/724, 720/726, 721/725, 726/731, 739/744, 740/745, 741/746, 742/747, 759/764, 760/765, 761/766, 762/767.
Send note to Staff  Go to Top of Page
Edited by jogil - 05/23/2018 10:46 am
Pillar Of The Community
2768 Posts
Posted 05/27/2018   9:36 pm  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
Some more to add the the list: Belgian Congo Scott # 139-156, B12-B20 There are probably more that can be added. This takes this list back to Belgium. There appears to be gaps in the listing since a Stickney press was first obtained in 1927 by Belgium's Stamp Printing Works in Mechelen/Malines. So far have found only Scott # 294-303, 305, 316-317 Are there any others?
Send note to Staff  Go to Top of Page
Edited by jogil - 05/27/2018 9:40 pm
Pillar Of The Community
2768 Posts
Posted 05/30/2018   11:10 am  Show Profile Check jogil's eBay Listings Bookmark this reply Add jogil to your friends list  Get a Link to this Reply
A Stickney press was used to print Belgium stamps from 1927 to 1950 by The Stamp Printing Works, Mechelen/Malines.

Some sheet stamps perforated gauge 11 x 11.5: CB1-CB2.

Some sheet stamps perforated gauge 11.5: 218-220, 222-224, 251-253, 305, 379, 381-385, 400, B64, B67, B71-B75, B80-B82, B93-B97, B118-B122, B220, B426-B431, B432-B436, B437-B441, B442-B446, B465-B466, B472-B476, B479, C8-C11, C12, CB3, O44-O46, Q176-Q179, Q180, Q266, CB13.

Some sheet stamps perforated gauge 13.5 x 14: B83, B156-B162, B477-B478, B482, Q193-Q207, Q211-Q215.

Some sheet stamps perforated gauge 14 x 13.5: 229-236, 294-303, 316-317, 386-389, B107-B113, B123-B124, B144-B150, B260-B263, B480-B481, B483-B484, O32, Q184-Q192, Q263-Q265.

Some sheet stamps perforated gauge 14: B65, B66, B68, B76-B77, B98, B101-B105, B323-B326, B327.

Belgian Congo sheet and booklet stamps perforated 11.5: 139-156, B12-B20.

Sheet and booklet stamps perforated 13.5 x 14: C7-C17.

Sheet stamps perforated 14: 115-135.

Ruanda-Urundi sheet stamps perforated 11.5: 37-54, 56-59.
Send note to Staff  Go to Top of Page
Edited by jogil - 05/30/2018 11:20 am
